Overview

The SICK RAY10-AB4CBL (Part No. 1091724) is a photoelectric retro-reflective sensor featuring a Reflex Array dual lens system for minimum distance to reflector detection. It utilizes PinPoint LED technology emitting visible red light at 635 nm with an average service life of 100,000 hours at +25 °C. The rectangular housing measures 21.5 mm x 36 mm x 37.7 mm. Key parameters include a sensing range of 0 m to 1.5 m and a detection height of 25 mm. It supports position-independent detection of objects as small as 5 mm within the light array.

Feature Summary

• Reflex Array dual lens system enables reliable detection at minimum distances to the reflector
• PinPoint LED light source provides high stability and long operational lifespan
• Capable of detecting transparent, perforated, uneven, shiny, and flat objects

Applications

• Detecting transparent objects
• Detecting perforated objects
• Detecting uneven or shiny surfaces
• Handling objects with position tolerances

Procurement Notes

Verify the specific part number against official documentation, as the provided data references Part No. 1091724 for the RAY10-AB4CBL model. Confirm compatibility with required reflectors, such as the P250F, to ensure the specified sensing range is achieved. Ensure environmental conditions align with the stated temperature requirements for optimal LED longevity.

Selection Notes

Select this sensor when applications require distinguishing between close-range targets and background clutter using a retro-reflective setup. The dual lens system is critical for scenarios where the sensor must be mounted very close to the reflector. Consider the visible red light emission for easier alignment during installation compared to infrared alternatives.

Part Context

This component belongs to the RAY10 series of photoelectric sensors manufactured by SICK. The series is designed for industrial automation tasks requiring precise object detection. The specific model integrates advanced optical technology to handle challenging surface types and varying object geometries effectively in automated production lines.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
