1085137

Overview

The SICK model 1085137 is a fixed mount barcode scanner from the CLV60x series, designed for identifying 1D codes at short reading distances. It utilizes a compact design with a 2K pixel CMOS sensor to ensure reliable reading performance. The device operates with a high scanning frequency of 750 Hz, making it suitable for fast industrial applications. Configuration is facilitated through the SOPAS ET user interface. The product is available in two voltage versions: 5 V and 12–24 V DC, both offering optional ESD protection. Communication interfaces include RS-232 or USB for controlling industrial devices.

Feature Summary

• Compact design with minimal space requirements for integration into small machines
• High scanning frequency of 750 Hz suited for fast applications
• Easy commissioning with plug-and-read USB interface and fixed focus adjustment
• Clearly visible multicolor status LED readable from virtually any viewing angle

Applications

• Identifying 1D codes at short reading distances
• Integration in small machines with limited space
• Fast applications requiring high scanning frequency

Procurement Notes

Verify the specific voltage variant (5 V or 12–24 V DC) required for your application when ordering. Confirm if ESD protection is needed, as it is an optional feature. Ensure compatibility with the SOPAS ET software for configuration. Check that the RS-232 or USB interface meets your system's connectivity requirements. Validate the short reading distance specifications against your operational needs.

Selection Notes

Select this model for applications requiring reliable 1D code reading at short distances within compact machinery. Choose between the 5 V and 12–24 V DC versions based on your power supply infrastructure. Consider the optional ESD protection if the operating environment poses electrostatic risks. The fixed focus design simplifies installation by eliminating the need for complex optical adjustments during commissioning.

Part Context

This component belongs to the SICK CLV60x series of fixed mount barcode scanners. The series is characterized by its cost-efficient price-performance ratio and long-term availability due to proven CMOS technology. It is engineered for easy operation and installation, featuring a clear concept designed to simplify plant operations. The series supports both RS-232 and USB communication interfaces for versatile industrial device control.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
