1087162

Overview

The SICK part number 1087162 corresponds to the RAY10-AB4CBL, a photoelectric retro-reflective sensor. This device utilizes a dual lens system with Reflex Array technology and PinPoint LED light source emitting visible red light at 635 nm. It features a rectangular housing measuring 21.5 mm x 36 mm x 37.7 mm. The sensor provides position-independent detection of objects as small as 5 mm within a 25 mm detection height. Maximum sensing range is up to 1.5 meters when used with the P250F reflector. Adjustment is performed via potentiometer.

Feature Summary

• Dual lens system with Reflex Array technology for minimum distance to reflector
• PinPoint LED light source for precise object detection
• Position-independent detection capability for small objects

Applications

• Detecting transparent objects
• Detecting perforated objects
• Detecting uneven or shiny objects
• Handling objects with position tolerances
• Detecting flat objects

Procurement Notes

Verify the specific ordering suffix against official SICK documentation to ensure correct configuration. Confirm compatibility with required reflectors, such as the P250F model, for optimal performance. Check technical drawings and connection diagrams for integration requirements. Ensure environmental conditions match the sensor's operational specifications. Consult official datasheets for detailed mechanical dimensions and electrical wiring details before procurement.

Selection Notes

Select this sensor for applications requiring reliable detection of challenging materials like transparent or reflective surfaces. The dual lens system offers advantages in close-proximity detection scenarios. Consider the rectangular housing design for space-constrained installations. Evaluate the need for potentiometer adjustment versus digital interfaces based on system complexity. Verify that the 1.5-meter range meets application requirements.

Part Context

This component belongs to the RAY10 series of photoelectric sensors from SICK. These sensors are designed for industrial automation tasks requiring precise object detection. The series emphasizes versatility through various optical technologies and housing designs. Integration into automated systems often involves pairing with compatible reflectors and mounting accessories.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
