1092553

Overview

The SICK 1092553 is a safety light curtain system designed for personnel protection in industrial environments. It features a resolution of 40 mm and a protective height of 600 mm, ensuring reliable detection of human limbs. The device operates with a response time of 30 ms and supports a maximum scanning frequency of 80 Hz. It utilizes a two-beam principle for high reliability and includes integrated diagnostics for continuous monitoring. The unit is housed in a robust aluminum profile suitable for harsh factory conditions.

Feature Summary

• Provides reliable personnel protection through precise detection of intrusions into hazardous areas
• Integrated diagnostic capabilities ensure continuous system monitoring and early fault detection
• Robust aluminum housing design withstands demanding industrial environmental conditions

Applications

• Protection of press brakes and stamping machines
• Safety guarding for injection molding equipment
• Personnel protection at automated assembly stations

Procurement Notes

Verify the specific order number against the technical datasheet to confirm compatibility with existing control systems. Ensure that the protective height and resolution meet the risk assessment requirements for the intended application. Confirm cable lengths and connector types required for integration. Always validate that the safety light curtain is installed according to manufacturer guidelines to maintain certification compliance.

Selection Notes

Select this model based on the required protective height and resolution determined by the machine's hazard analysis. Ensure the operating range matches the distance between the transmitter and receiver units. Verify that the control interface is compatible with the plant's safety PLC or controller. Consider environmental factors such as ambient light interference when choosing the appropriate variant.

Part Context

This component belongs to SICK's safety light curtain product line, which focuses on non-contact safety solutions for machinery. These devices are engineered to comply with international safety standards including ISO 13849 and IEC 61496. The series is widely used across manufacturing sectors to safeguard operators from moving mechanical parts.

Replacement Considerations

When replacing older models, verify that the new unit meets the same performance level (PL) and category requirements. Check for compatibility with existing mounting brackets and wiring harnesses. Ensure that the replacement part has the same resolution and protective height to maintain the original safety integrity level.
