1092678

Overview

The SICK model 1092678 is an RFID read/write device belonging to the RFU61x series, specifically configured as a short-range unit. It operates within the UHF frequency band (860 MHz to 960 MHz) and supports EPCglobal UHF Class 1 Generation 2, ISO/IEC 18000-6 C, and RAIN protocols. The device features an integrated antenna with a circular polarization type and a typical axial ratio of 3 dB. It provides an output power of 25 mW (ERP, 14 dBm) and utilizes PoE for connection. The unit offers a reading range of up to 0.5 meters depending on the transponder used and ambient conditions.

Feature Summary

• Short-range identification capability with integrated antenna
• Support for multiple UHF RFID standards including ISO/IEC 18000-6 C
• Power over Ethernet connectivity for simplified installation

Applications

• Automotive electronics component identification
• Printed circuit board panel identification
• ESD-safe electronic component tracking

Procurement Notes

Verify that the specific ordering suffix matches the required cable length and connector type for your installation. Confirm that the UHF frequency configuration aligns with local regulatory requirements in your deployment region. Ensure the mounting kit is included or ordered separately if not part of the standard package. Check compatibility with existing PLC networks supporting PROFINET IO/RT.

Selection Notes

Select this model when short-range identification is sufficient for the application. The integrated antenna design simplifies mechanical integration compared to external antenna setups. Consider the 0.5-meter reading range limitation against the physical distance between the reader and the target tags. Verify that the PoE requirement can be met by the network infrastructure.

Part Context

This component is part of the SICK RFU61x product family, which focuses on UHF RFID technology for industrial automation. The series is designed for reliable data collection in manufacturing environments. It complements other SICK sensors by providing non-contact identification capabilities essential for traceability and process control in modern production lines.

Replacement Considerations

Check for updated part numbers within the RFU61x series that may offer revised firmware or connector options. Ensure any substitute maintains the same UHF frequency band and protocol support. Verify that the replacement unit fits the existing mounting bracket dimensions.
