10DBAG5

Overview

The Delta Electronics 10DBAG5 is a single-phase EMI/RFI power line filter module designed for general-purpose applications. It operates at a rated current of 10 A and supports voltage ratings of 115 VAC and 250 VAC across 50/60 Hz frequencies. The unit features a single-stage filtering architecture with chassis mounting capabilities. Electrical connections are facilitated via lug-to-lug terminals, ensuring secure integration into power distribution systems requiring electromagnetic interference suppression.

Feature Summary

• Single-stage EMI/RFI suppression for power line filtering
• Chassis mount design for stable installation
• Lug-to-lug terminal configuration for direct wiring

Applications

• General purpose electronic equipment power input
• Industrial control system power conditioning
• Medical device power supply filtering

Procurement Notes

Verify the specific voltage rating requirements against the 115V or 250VAC specifications before procurement. Confirm that the lug-to-lug terminal style matches your existing wiring harness or busbar setup. Ensure the chassis mounting dimensions align with your enclosure design to guarantee proper fit and mechanical stability during operation.

Selection Notes

Select this component when a single-stage filter solution is sufficient for your electromagnetic compatibility needs. The 10A current rating suits moderate power applications. Consider the lug-to-lug termination if soldering or crimping options are preferred over screw terminals. Verify that the chassis mounting style fits your available panel space.

Part Context

This part belongs to Delta Electronics' general-purpose power line filter series. These modules are engineered for broad industrial and commercial use cases where standard EMI attenuation is required. The product line emphasizes reliability and straightforward integration into AC power inputs for various electronic devices.

Replacement Considerations

Consult official Delta Electronics documentation for verified substitute part numbers. Do not assume cross-compatibility with other manufacturers without verifying electrical parameters and physical dimensions.
