Product Detailed Parameters
- Description：LINE FILTER 250VAC 10A CHASS MNT
- Series：H
- Mfr：TE Connectivity Corcom Filters
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：250V
- Current：10:00 AM
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：CSA, UR, VDE
- Operating Temperature：-10°C ~ 40°C
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：360µH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The TE Connectivity Corcom Filters 10EH1 is a single-phase EMI/RFI line filter designed for chassis or panel mounting. It features a two-element circuit configuration providing basic attenuation above 1MHz. The component supports a rated current of 10A at AC voltages of 120V and 250V, operating within a frequency range of 50/60Hz. Termination is achieved via .250-inch Faston terminals for both input and output connections.
Feature Summary
- Two-element circuit design for effective EMI suppression
- Suitable for medical equipment applications
- Faston terminal termination for simplified wiring
Applications
- Medical equipment power supplies
- General electronic device noise filtering
- Industrial control systems requiring EMI reduction
Procurement Notes
Verify the specific datasheet version to confirm exact dimensional tolerances and terminal spacing before integration. Ensure that the mounting hardware accommodates the chassis or panel installation requirements specified in the official documentation. Cross-reference the manufacturer part number with internal BOMs to avoid substitution errors during assembly.
Selection Notes
Select this model when basic EMI attenuation above 1MHz is sufficient for the application. The 10A rating and dual voltage support make it versatile for various international standards. Consider the physical dimensions and Faston termination style to ensure compatibility with existing PCB layouts or wire harnesses.
Part Context
Part of the Corcom H series, the 10EH1 is engineered for reliable noise filtration in sensitive environments. It complements other Corcom filters by offering a compact solution for single-phase applications where space constraints and standard termination types are critical factors in system design.
Replacement Considerations
Consult the official Corcom selector chart for direct equivalents. Verify that any substitute maintains the same current rating, voltage class, and termination style to ensure mechanical and electrical compatibility without redesigning the enclosure or wiring.
