10EK1

Overview

The TE Connectivity Corcom Filters 10EK1 is a single-phase EMI/RFI power line filter designed for commercial applications. It features a 10A current rating and operates at 250VAC, 50/60Hz. The unit utilizes a single-stage filtering configuration with quick-connect terminals (0.187 inch) for chassis mounting. Certified by CSA, UL, and VDE, it includes a voltage selector feature.

Feature Summary

• Engineered specifically for high impedance loads
• Integrated voltage selector capability
• Single-stage EMI/RFI noise suppression

Applications

• High impedance load equipment
• Commercial electronic devices
• General-purpose RFI power line filtering

Procurement Notes

Verify the specific terminal pitch and panel cutout dimensions against the official datasheet before integration. Confirm that the voltage selector mechanism aligns with the target system's input requirements. Ensure the chassis mounting style matches the enclosure design constraints.

Selection Notes

Select this component when high impedance loads are present in the circuit. The single-stage design offers cost-effective noise reduction for general commercial use. Verify compatibility with 250VAC systems and ensure sufficient space for chassis mounting and quick-connect wiring.

Part Context

Part of the Corcom K Series, the 10EK1 addresses common mode interference in AC power lines. It serves as a fundamental protection component for sensitive electronics requiring compliance with commercial EMI standards while maintaining operational stability under varying load conditions.

Replacement Considerations

Public confirmed substitute part numbers: None available.
