10EMC6

Overview

The TE Connectivity Corcom Filters 10EMC6 is a single-phase EMC/EMI line filter designed for chassis mounting. It operates at frequencies of 50 Hz and 60 Hz with a rated AC voltage of 250 VAC. The component supports a current rating of 10 A and features a dual-stage configuration to suppress electromagnetic interference. Termination is achieved via quick-connect terminals, ensuring secure electrical connections within power entry modules.

Feature Summary

• Dual-stage filtering architecture for enhanced noise attenuation
• Quick-connect terminal style for efficient assembly
• Chassis mount installation type for structural stability

Applications

• Industrial automation equipment
• Medical devices
• General purpose power supply units

Procurement Notes

Verify the specific datasheet version and compliance certifications (UL, CSA, VDE) prior to procurement. Confirm that the quick-connect terminal dimensions match the mating connector specifications in your design. Ensure the operating temperature range aligns with the environmental conditions of the final enclosure.

Selection Notes

Select this model when a single-phase, 10 A solution with dual-stage suppression is required. Compare against the 10VS1 or 6ET1 models if different current ratings or stage configurations are needed. Verify that the 250 VAC rating meets the system's maximum line voltage requirements without derating issues.

Part Context

This component belongs to the Corcom single-phase filter series by TE Connectivity. These filters are engineered for compact integration into power entry modules and industrial enclosures. The series provides standardized solutions for meeting international EMC standards across various commercial and industrial sectors.

Replacement Considerations

Publicly confirmed substitute part numbers for the 10EMC6 are not available in the provided documentation. Consult TE Connectivity technical support for direct equivalents or cross-reference options based on specific performance criteria.
