10ESK7

Overview

The TE Connectivity Corcom Filters 10ESK7 is a single-phase, single-stage power line filter designed for EMI/RFI suppression. It features a chassis mount configuration with IEC 320-C14 input and quick connect terminals. The unit supports a rated current of 10 A at 250 VAC and operates at 50 Hz or 60 Hz frequencies. Key electrical specifications include an inductance of 7.13 mH and a leakage current of 360 uA. It holds UL, CSA, VDE, and EN certifications.

Feature Summary

• Provides single-stage EMI/RFI filtering for AC power lines
• Integrates IEC 320-C14 receptacle interface for plug-in connectivity
• Supports chassis mounting via flange design
• Includes quick-connect terminal options for circuit integration

Applications

• General purpose electronic equipment power conditioning
• Industrial control systems requiring EMI suppression
• Medical device power entry modules
• Commercial machinery noise reduction

Procurement Notes

Verify the specific datasheet version to confirm compliance with current RoHS and REACH standards. Ensure the installation environment accommodates the required chassis opening dimensions and thermal conditions. Confirm that the 10 A current rating aligns with the system's maximum load requirements to prevent overheating or performance degradation during operation.

Selection Notes

Select this component when a single-phase filter with integrated IEC 320-C14 receptacle is required. The 10 A rating suits moderate power applications. Verify that the 7.13 mH inductance provides sufficient attenuation for the target noise spectrum. Consider the chassis mount style if panel space allows for flange securing rather than PCB mounting alternatives.

Part Context

This part belongs to the TE Connectivity Corcom SK series, which covers filters ranging from 3 to 10 Amps. The series is designed for general-purpose power line filtering. The 10ESK7 represents the higher current end of this specific single-stage lineup, offering robust noise suppression capabilities for standard AC mains applications.

Replacement Considerations

The part number 1-6609035-1 is listed as an alias for this component. Verify mechanical fit and electrical parameters before substituting with other single-phase filters in the Corcom K or SK series.
