Product Detailed Parameters
- Description：MOLDED UNSHIELDED RF COILS AXIAL
- Series：10M
- Mfr：Gowanda Electronics
- Package：Tape & Reel (TR)
- Type：Wirewound
- Material - Core：Iron Powder
- Inductance：5.6 µH
- Tolerance：±10%
- Current Rating (Amps)：185 mA
- Current - Saturation (Isat)：-
- Shielding：Unshielded
- DC Resistance (DCR)：1.8Ohm Max
- Q @ Freq：50 @ 7.9MHz
- Frequency - Self Resonant：65MHz
- Ratings：-
- Operating Temperature：-55°C ~ 105°C
- Inductance Frequency - Test：7.9 MHz
- Mounting Type：Through Hole
- Package / Case：Axial
- Supplier Device Package：Axial
- Size / Dimension：0.095" Dia x 0.250" L (2.41mm x 6.35mm)
- Height - Seated (Max)：-
- Features：-
Download product information
Overview
The 10M561K is a fixed wirewound inductor manufactured by Gowanda Electronics. It features an unshielded axial lead configuration with an inductance of 5.6 µH. The component supports a maximum current rating of 185 mA and exhibits a maximum DC resistance of 1.8 Ohms. Designed for robust performance, it utilizes non-magnetic construction to prevent magnetic interference in sensitive circuits.
Feature Summary
- Unshielded wirewound design suitable for high-frequency applications
- Non-magnetic construction prevents interference in sensitive environments
- Axial leaded package facilitates through-hole PCB mounting
Applications
- Aerospace electronic systems
- Defense circuitry
- Medical device electronics
Procurement Notes
Verify the specific manufacturer datasheet for detailed electrical tolerances and thermal characteristics before integration. Confirm that the axial lead spacing matches your printed circuit board layout requirements. Ensure the 185 mA current limit aligns with your system's operational load to prevent component failure.
Selection Notes
Select this component when non-magnetic properties are critical to avoid signal distortion in adjacent circuitry. The unshielded design requires careful placement to minimize electromagnetic coupling with nearby traces. Verify that the 5.6 µH inductance value meets the specific filtering or energy storage needs of the target application circuit.
Part Context
This part belongs to Gowanda Electronics' portfolio of high-performance inductors and custom magnetics. The company specializes in components engineered specifically for demanding sectors including aerospace, defense, and medical industries. These products are designed to withstand rigorous environmental conditions while maintaining stable electrical performance.
Replacement Considerations
The ER10M561KP is a molded variant from the same manufacturer offering similar electrical specifications but with different physical packaging. Cross-reference mechanical dimensions and lead configurations carefully to ensure compatibility with existing assembly processes.
