Overview

The Gowanda Electronics 10M563J is a general-purpose, unshielded wirewound inductor designed for through-hole mounting. It features an axial lead configuration with a ferrite core and rectangular construction. The component has a nominal inductance of 560 µH with a tolerance of ±5%. It exhibits a maximum DC resistance of 46 Ohms and a rated current of 35 mA. The device operates within a temperature range of -55°C to 125°C and is specified for RF coil applications.

Feature Summary

• Unshielded wirewound design utilizing a ferrite core for stable inductance characteristics
• Axial through-hole package suitable for standard PCB mounting processes
• Engineered specifically for radio frequency (RF) coil implementations

Applications

• Radio frequency signal processing circuits
• General purpose filtering applications
• Industrial electronic systems requiring robust passive components

Procurement Notes

Verify the specific suffix requirements for your application, as the base model may be available in leaded or RoHS-compliant variants. Confirm that the 35 mA current rating and 46 Ohm DC resistance align with your circuit's power budget. Ensure the axial lead dimensions match your board layout constraints before finalizing procurement.

Selection Notes

Select this component when a high-inductance value is required in a compact axial form factor. The unshielded nature necessitates careful placement to avoid magnetic coupling with nearby sensitive traces. Consider the self-resonant frequency limitations inherent to wirewound designs at higher frequencies.

Part Context

This part belongs to the 10M series of traditional RF inductors manufactured by Gowanda Electronics. The series offers various inductance values ranging from 0.1 µH to higher microhenry levels, all sharing similar axial leaded construction and ferrite core technology for consistent performance across different RF stages.

Replacement Considerations

Direct substitutes include other Gowanda 10M series parts with matching inductance, such as 10M562J if lower inductance is acceptable. Cross-manufacturer replacements must match the 560 µH value, axial package, and current handling capabilities while verifying core material compatibility.
