Product Detailed Parameters
- Description：MOLDED NON-MAGNETIC INDUCTOR AXL
- Series：10MG
- Mfr：Gowanda Electronics
- Package：Tape & Reel (TR)
- Type：Molded
- Material - Core：Non-Magnetic
- Inductance：1 µH
- Tolerance：±10%
- Current Rating (Amps)：385 mA
- Current - Saturation (Isat)：-
- Shielding：Unshielded
- DC Resistance (DCR)：1Ohm Max
- Q @ Freq：25 @ 25MHz
- Frequency - Self Resonant：230MHz
- Ratings：-
- Operating Temperature：-55°C ~ 125°C
- Inductance Frequency - Test：25 MHz
- Mounting Type：Through Hole
- Package / Case：Axial
- Supplier Device Package：Axial
- Size / Dimension：0.095" Dia x 0.250" L (2.41mm x 6.35mm)
- Height - Seated (Max)：-
- Features：-
Download product information
Overview
The 10MG101K is a fixed molded inductor manufactured by Gowanda Electronics. It features an axial lead configuration and utilizes non-magnetic materials for its core construction. The component provides a nominal inductance of 1 µH with a maximum DC resistance of 1 Ohm. It supports a maximum current rating of 385 mA. This part is designed for applications requiring magnetic neutrality, such as medical imaging environments.
Feature Summary
- Non-magnetic core construction prevents interference with sensitive systems
- Molded design ensures mechanical stability and environmental protection
- Axial lead configuration facilitates through-hole mounting
Applications
- Medical imaging equipment such as MRI systems
- Aerospace and defense electronic circuits
- Industrial RF applications requiring magnetic neutrality
Procurement Notes
Verify RoHS compliance status as the manufacturer offers both compliant and leaded variants. Confirm that the specific order matches the required non-magnetic specification. Ensure the axial package style aligns with the target PCB layout requirements before finalizing procurement.
Selection Notes
Select this component when system performance requires inductors that do not generate or respond to external magnetic fields. The 1 µH value and 385 mA current rating suit low-power RF filtering needs. Verify thermal limits against operating conditions to ensure reliability within the specified temperature range.
Part Context
Gowanda Electronics specializes in high-performance magnetics for critical sectors including aerospace, defense, and healthcare. The company maintains ISO 9001, AS9100, and ISO 13485 certifications. Their product portfolio includes custom and standard inductors designed for rigorous operational environments.
Replacement Considerations
Cross-reference with other Gowanda non-magnetic axial inductors like the 10MG100K for different inductance values. Ensure substitute parts maintain identical non-magnetic material properties to preserve system integrity in sensitive applications.
