Product Detailed Parameters
- Description：LINE FILTER 250VAC 10A CHASS MNT
- Series：B
- Mfr：TE Connectivity Corcom Filters
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：250V
- Current：10:00 AM
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：CSA, UR, VDE
- Operating Temperature：-10°C ~ 40°C
- Mounting Type：Chassis Mount
- Termination Style：Wire Leads
- Inductance：495µH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The TE Connectivity Corcom Filters 10VB3 is a single-phase EMI/RFI power line filter designed for chassis mounting. It features wire lead termination and operates at 50/60 Hz with a rated current of 10 A and voltage of 120V/250VAC. The component belongs to the B series, which covers ratings from 1 to 30 Amps. It includes flange mount installation and is certified by UL.
Feature Summary
- Single-phase EMI/RFI filtering configuration
- Flange mount chassis installation style
- Wire lead termination method
Applications
- General purpose power line filtering
- Industrial equipment EMC suppression
- Medical device power entry modules
Procurement Notes
Verify the specific datasheet version for the 10VB3 model to confirm exact leakage current specifications and mechanical dimensions. Ensure compatibility with the target chassis thickness and wire gauge requirements before procurement. Confirm that the wire lead length meets the assembly constraints of the final enclosure design.
Selection Notes
Select this component when a 10A single-phase filter with wire leads is required. The B series offers a range of current ratings. Verify that the flange mount style fits the available panel space. Consider the operating temperature range and certification requirements such as UL compliance for the intended market.
Part Context
This part belongs to the TE Connectivity Corcom Filters B series, which provides power line filters ranging from 1 to 30 Amps. The series is known for providing EMI/RFI suppression in various industrial and commercial applications. The 10VB3 specifically utilizes a flange mount design with wire leads for easy integration into power entry systems.
Replacement Considerations
Check for direct substitutes within the Corcom B series or other TE Connectivity filter families. Verify that any replacement matches the 10A rating, 120/250VAC voltage, and flange mount form factor. Ensure equivalent certification approvals are present.
FAQ
What is the leakage current specification for the 10VB3?
The leakage current is specified as 700 uA.
Is the 10VB3 suitable for medical applications?
Yes, it is listed for use in medical device power entry modules.
