1103483

Overview

The SICK 1103483 is a component of the AHM36A-SCQC000A30 absolute encoder system, specifically identified as the mounting flange (BEF-FA-020-036). This mechanical accessory facilitates the secure installation of the AHS/AHM36 series absolute encoders. The part serves as a structural interface for integrating the encoder into machinery. It is supplied as part of a complete assembly package that includes the measuring wheel mechanics and the encoder unit itself. The component ensures proper alignment and stability for the associated sensing equipment.

Feature Summary

• Provides a dedicated mounting interface for the AHM36 series absolute encoders
• Ensures stable mechanical integration within industrial automation setups
• Functions as a critical structural element in the complete measuring wheel assembly

Applications

• Mounting absolute encoders on industrial machinery
• Integration into automated measurement systems
• Installation of measuring wheel mechanics

Procurement Notes

Verify the part number against the official SICK datasheet to confirm it corresponds to the BEF-FA-020-036 mounting flange. Ensure compatibility with the AHM36A-SCQC000A30 encoder variant. Check that the required accessories, such as the measuring wheel mechanics, are included if a full assembly is needed. Confirm technical specifications match the application requirements before purchase.

Selection Notes

Select this part when installing the AHM36 series absolute encoder requires a specific mounting flange. It is essential for applications needing precise encoder positioning. Verify that the housing dimensions and interface types align with the existing machinery design. Consider the complete kit availability if additional components like measuring wheels are required for the system.

Part Context

This item belongs to the SICK AHM36 absolute encoder family, designed for robust position feedback. It is often distributed as part of a comprehensive solution including mechanics and sensors. The product line supports various industrial automation tasks requiring reliable data acquisition. The component is manufactured by SICK AG, a leading provider of sensor technology.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult SICK technical support for compatible alternatives or updated model equivalents.
