Overview

The SICK DFS60S-TGOC01024 is an absolute rotary encoder designed for industrial automation. It features a single-turn resolution of 1024 pulses per revolution and utilizes a CANopen interface for data transmission. The device supports safety-related parameters including SIL 2 (IEC 61508) and PL d (EN ISO 13849). Key technical specifications include a safety-related measuring step of 0.09 degrees, a safety-related accuracy of ± 0.09 degrees, and a mean probability of dangerous failure per hour (PFH) of 1.7 x 10^-8. The mission time is rated at 20 years under specific diagnostic coverage conditions.

Feature Summary

• Integrates safety-related functions compliant with SIL 2 and PL d standards for secure machine operation.
• Provides high-precision angular measurement with a safety-related accuracy of ± 0.09 degrees.
• Supports CANopen communication protocol for reliable data exchange in industrial networks.

Applications

• Safety-critical rotating machinery requiring certified position feedback
• Industrial automation systems utilizing CANopen fieldbus communication
• Machinery adhering to EN ISO 13849 performance level requirements

Procurement Notes

Verify the exact configuration with the relevant SICK branch office to ensure compliance with specific machine unit safety requirements. Confirm that the external drive system achieves the necessary 99% diagnostic coverage to validate the stated PFH values. Ensure operating temperature conditions do not exceed 95 °C for accurate parameter validation during procurement planning.

Selection Notes

Select this model when both standard position feedback and functional safety are required within a single component. The CANopen interface suits environments where this protocol is the standard for networked devices. Consider the 0.09-degree resolution if precise angular positioning is critical for the application's operational safety and control logic.

Part Context

This part belongs to the DFS60S series of absolute encoders from SICK. The series is characterized by robust construction suitable for demanding industrial environments. The specific suffix TGOC01024 denotes the electrical interface, resolution, and mounting configuration unique to this variant within the broader product family.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing CANopen networks and mechanical mounting constraints before considering alternative models from other manufacturers.
