1108692

Overview

The SICK model 1108692 is a DFS60S-TGOC01024 absolute encoder. It features a hollow shaft design with a 10 mm bore diameter and an IP67 protection rating for industrial environments. The device provides a single-turn resolution of 12-bit data via a BiSS-C interface. Safety parameters include SIL 2 (IEC 61508), SILCL2 (IEC 62061), and PL d (EN ISO 13849). The mean probability of dangerous failure per hour is 1.7 x 10^-8, based on a diagnostic coverage of 99% and an operating temperature of 95 °C.

Feature Summary

• Hollow shaft construction accommodating a 10 mm diameter shaft
• Integrated safety functions compliant with international standards
• BiSS-C digital interface for high-speed data transmission

Applications

• Safety-related rotary motion control systems
• Industrial automation machinery requiring certified position feedback
• Applications demanding high reliability in harsh environments

Procurement Notes

Verify the specific ordering suffix to ensure compatibility with required interface protocols and mounting configurations. Confirm that the external drive system achieves the necessary diagnostic coverage to maintain stated safety integrity levels. Check environmental ratings against operational temperature extremes. Ensure mechanical dimensions match the installation space constraints. Validate cable length requirements for signal integrity.

Selection Notes

Select this component when a certified safety-rated absolute encoder is required for rotary applications. The hollow shaft design simplifies integration into existing drive trains without additional coupling mechanisms. Consider the BiSS-C interface for high-performance communication needs. Evaluate the safety parameters against the specific machine's risk assessment requirements. Ensure the IP67 rating meets the environmental exposure conditions.

Part Context

This part belongs to the DFS60S series of absolute encoders from SICK. The series is designed for precise position measurement in industrial settings. The model number indicates specific configuration options including interface type and safety certification level. It represents a specialized solution for applications where both precision and functional safety are critical operational requirements.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official SICK resources for cross-referencing compatible variants or updated models within the DFS60S family.
