1109366

Overview

The SICK 1109366 is a mechanical rotary encoder from the DUV60 series, designed for industrial automation applications. It features an axial actuator and flange mounting configuration with a connector termination style. The device operates on a supply voltage range of 4.75V to 30V and delivers 1800 pulses per revolution in an incremental quadrature output format. Directionality is user-selectable, allowing flexible integration into control systems. The unit is rated for a minimum rotational life of 3.6 billion cycles and is currently available as an active component.

Feature Summary

• Mechanical incremental quadrature output generation
• User-selectable rotation direction capability
• Robust axial shaft actuator design
• Standardized flange mounting interface

Applications

• Industrial machinery position monitoring
• Automated material handling systems
• Conveyor belt speed and position tracking
• General factory automation equipment

Procurement Notes

Verify the specific suffix codes against the official datasheet to ensure correct cable length, connector type, and shaft configuration match your system requirements. Confirm that the operating voltage range aligns with your PLC or controller inputs. Check for any required accessories such as coupling adapters or mounting hardware not included in the standard package.

Selection Notes

Select this model when a robust mechanical solution with high cycle life is required for incremental position feedback. Ensure the axial shaft diameter and keyway specifications match your drive mechanism. Consider the connector type compatibility with your existing cabling infrastructure before finalizing the order.

Part Context

This component belongs to the SICK DUV60 series of mechanical encoders, which are engineered for demanding industrial environments. The series emphasizes durability and precise signal generation for standard automation tasks. SICK Inc. manufactures these sensors to meet international quality standards for reliability in continuous operation scenarios.

Replacement Considerations

Consult the official SICK replacement guide for direct equivalents. Verify pinout compatibility and mounting dimensions if substituting with other brands. Ensure the pulse count and electrical characteristics match the original system requirements to avoid signal integrity issues.
