Overview

The SICK IQ40-20BPSKC0K is a proximity sensor from the IQ40 series, designed for industrial automation. It features a rectangular housing with a short form factor, measuring 40 mm in width and height, and 66 mm in depth. The device utilizes an M12, 4-pin connector for connection, which is rotatable by 270 degrees with detent functionality. It operates on a PNP switching output with a make contact function and supports DC 3-wire electrical execution. The sensor provides a guaranteed switching distance of 16.2 mm and a nominal switching distance of 20 mm. It is rated IP67 for protection against dust and water ingress and functions at a switching frequency of 100 Hz.

Feature Summary

• Compact rectangular housing design suitable for space-constrained installations
• Rotatable M12 connector allows for flexible cable routing orientation
• Flush mounting capability ensures seamless integration into metallic surfaces
• High switching frequency supports rapid detection cycles

Applications

• Automated assembly line positioning
• Packaging machine object detection
• Conveyor system control
• Industrial robot end-of-arm tooling

Procurement Notes

Verify that the specific ordering number matches the required switching distance and output type. Confirm the connector rotation requirement aligns with the mechanical layout. Ensure the installation environment meets the IP67 rating specifications. Check compatibility with the existing PLC input voltage levels for the PNP configuration.

Selection Notes

Select this model when a flush-mountable proximity sensor with a compact footprint is required. The 20 mm switching distance suits applications involving standard metal targets. The M12 interface ensures standardized connectivity within modern industrial networks. Consider the 100 Hz frequency limit for high-speed cycle requirements.

Part Context

This component belongs to the SICK IQ40 series, which focuses on robust proximity sensing solutions. The series emphasizes durability and ease of integration into various automation setups. The IQ40 line typically includes variants with different switching distances and output configurations to cover diverse industrial needs.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
