1111002

Overview

The SICK model 1111002 is the scanGrid2 I/O safety light curtain, a Type 4 PL e safety device designed for hazardous area protection. It features an 8-channel digital input and output interface via an M12 connector. The unit operates within a standard industrial environment with a protective housing rated IP65/IP67 against dust and water ingress. It supports series connection capabilities to facilitate multi-zone safety setups in automated machinery.

Feature Summary

• Provides reliable object detection using high-performance ASIC technology with immunity to ambient light
• Features pinpoint LED technology for precise alignment and highly visible status indication
• Offers versatile mounting options including dovetail and side mounting for flexible installation

Applications

• Hazardous area protection in material handling systems
• Safety guarding for packaging machinery
• Industrial automation zones requiring Type 4 performance level

Procurement Notes

Verify the specific ordering code matches the required channel count and resolution. Confirm that the M12 connector type aligns with existing cabling infrastructure. Ensure the selected variant meets the necessary safety integrity level for the intended machine application before procurement.

Selection Notes

Select this model when an 8-channel I/O interface is required for safety light curtains. Consider the IP65/IP67 rating for environments with dust or washdown requirements. Evaluate the need for series connection capabilities if multiple units are deployed in sequence.

Part Context

This component belongs to the scanGrid2 family of safety light curtains from SICK. The family provides modular safety solutions for industrial applications. The scanGrid2 series emphasizes compact design and ease of setup through uniform mounting systems and clear status LEDs across variants.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
