1111208

Overview

The SICK part number 1111208 corresponds to the DSL-1208-G1M5C, an 8-core sensor and excitation cable. It features M12 connectors with a straight configuration for both the A-head socket and B-head plug. The cable is constructed from halogen-free PUR material, measuring 1.5 meters in length with a diameter of 5.9 mm. It supports a maximum operating voltage of 30 V and a current capacity of 4 A. The connector housing utilizes die-cast zinc with nickel plating, requiring a tightening torque of 0.4 Nm.

Feature Summary

• Halogen-free PUR cable construction suitable for demanding industrial environments
• Robust metal connector housing with standardized M12 interface
• Designed for integration with sensor and excitation circuits

Applications

• Oil and lubricant areas
• Conveyor belt operation
• Sensor and excitation signal transmission

Procurement Notes

Verify that the specific application requires an 8-core configuration, as wire color coding is not standardized across all manufacturers. Confirm compatibility with the target device's M12 pin assignment. Ensure the 1.5-meter length meets spatial requirements. Check environmental ratings against local conditions, noting the IP65/67/68 protection levels and temperature ranges for fixed or dynamic installation scenarios.

Selection Notes

Select this component when an 8-wire connection is necessary for sensor or excitation signals. Consider the 1.5-meter length and M12 straight connectors for standard panel or machine integration. Evaluate the halogen-free PUR jacket for compliance with safety regulations regarding smoke density in case of fire. Assess mechanical stress requirements against the specified bending radius and cycle life data.

Part Context

This cable belongs to the DSL series of sensor accessories manufactured by SICK. These components are designed to facilitate reliable electrical connections between sensors and control systems. The product line emphasizes durability and ease of integration into automated machinery, supporting various industrial communication and power distribution needs through standardized interfaces.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
