Product Detailed Parameters
- Description：Interconnect Misc
- Series：*
- Mfr：Phoenix Contact
- Package：Bulk
Download product information
Overview
Phoenix Contact part number 1113292 is a COMBICON MCS series PCB plug connector. It features 4 poles with a 5.0 mm pitch and accepts conductors up to 2.5 mm² using spring-cage technology. The unit is rated for 630 V and 12 A, with a UL rating of 320 V. Constructed from polyamide (PA) in grey, it includes an integrated locking lever for secure mating. The component complies with IEC 61984 standards for non-switching capacity connectors.
Feature Summary
- Utilizes spring-cage connection technology for tool-free wiring installation.
- Features an integrated locking lever mechanism to ensure secure mating stability.
- Designed as a non-switching capacity connector compliant with IEC 61984.
Applications
- Industrial control cabinet signal distribution
- Automation system interconnections
- PCB-to-wire interface modules
Procurement Notes
Verify the specific ordering suffix against the official Phoenix Contact datasheet to confirm pitch, current rating, and connection method. Ensure the selected variant matches the required voltage class and housing material specifications for the target application environment.
Selection Notes
Select this component when a reliable, high-density PCB plug is required for signal transmission. The spring-cage design supports both solid and stranded wires without ferrules, simplifying assembly compared to screw-type alternatives while maintaining robust mechanical retention.
Part Context
This component belongs to the COMBICON MCS product line, designed for compact PCB mounting. It serves as a male plug counterpart to corresponding base connectors, facilitating modular system expansion and maintenance within industrial automation and control engineering applications.
Replacement Considerations
Consult the Phoenix Contact Cross Reference Search for verified substitutes. Generic equivalents may lack the specific locking lever geometry or UL certification required for compliance in regulated environments.
