1114747

Overview

SICK part number 1114747 is a C4P-03031C00 light curtain belonging to the DETEC series. It provides machine safety protection for hands and arms with a resolution of 30mm and a protective height of 300mm. The device operates on a 24VDC supply voltage and features an IP65 rating for dust and water resistance. It supports a working range from 0 to 30.0 meters and functions within a temperature range of 0°C to 55°C.

Feature Summary

• Provides optical safety protection for hands and arms using a 30mm beam resolution.
• Features a compact design with a 300mm protective height for space-constrained applications.
• Includes integrated IP65 rated housing for reliable operation in industrial environments.

Applications

• Protecting access points to hazardous machinery zones
• Safety guarding for automated assembly lines
• Machine tool perimeter protection

Procurement Notes

Verify the specific model suffix against official SICK documentation to ensure correct configuration. Confirm that the required cable assemblies are ordered separately, as they are typically not included. Check for any necessary mounting accessories compatible with the 300mm height specification before finalizing the purchase order.

Selection Notes

Select this unit when a 30mm resolution is sufficient for hand or arm protection. Ensure the application requires a 300mm vertical coverage area. Verify that the operating environment falls within the specified 0°C to 55°C temperature range and meets IP65 ingress protection requirements.

Part Context

This component is part of the SICK DETEC series, designed for cost-effective machine safety solutions. It utilizes through-beam technology to create a protective field. The series is widely used in industrial automation for basic safeguarding tasks where high-resolution detection is not strictly required.

Replacement Considerations

Consult official SICK substitution guides for verified equivalents. Generic replacements may lack certified safety integrity levels. Ensure any substitute maintains the same 30mm resolution and 300mm height specifications.

FAQ

What is the resolution of the C4P-03031C00?

The resolution is 30mm, suitable for detecting hands and arms.

Does this light curtain include cables?

No, cable assemblies are typically sold separately and must be selected based on length requirements.
