1115869

Overview

The SICK 1115869 is a receiver component of the deTec4 Core safety light curtain system, designed for normal industrial environments. It features a scanning range of 15 meters and a protective field height of 1,350 millimeters. The unit provides a resolution of 30 millimeters with an optical synchronization capability and a response time of 12 milliseconds. It operates without blind zones and is compatible with the sender part number 1211503.

Feature Summary

• Optical synchronization functionality
• No blind zone design
• Compatible with specific sender units

Applications

• Normal industrial environment safety monitoring
• Machine guarding applications
• Protective field establishment

Procurement Notes

Verify that the required resolution matches the application needs, as this model is fixed at 30 mm. Confirm compatibility with the designated sender unit to ensure proper optical synchronization. Check if the included test rod corresponds to the specified resolution for accurate installation verification. Ensure the protective field height meets the safety requirements of the machinery being protected.

Selection Notes

Select this receiver when a 15-meter scanning range and 1,350-millimeter protective height are required. The 30-millimeter resolution determines the detection capability for objects within the field. Optical synchronization is necessary if multiple systems operate in proximity. Verify that the operating environment falls within the 'normal industrial' classification defined by the manufacturer.

Part Context

This component belongs to the deTec4 Core series of safety light curtains manufactured by SICK. It functions as the receiver unit in a paired system, requiring a corresponding sender for operation. The product line is engineered for standard industrial safety applications, providing reliable protective field monitoring through optical sensing technology.

Replacement Considerations

Ensure any substitute maintains the 30 mm resolution and 15 m scanning range. Compatibility with the original sender unit must be verified. The replacement must support optical synchronization and offer equivalent protective field dimensions.

FAQ

What is the maximum scanning range of this receiver?

The maximum scanning range is 15 meters.

Does this unit have blind zones?

No, this unit is designed with no blind zones.
