Overview

The SICK DL100-22AA2112 is a safety light curtain designed for personnel protection in industrial environments. It features a resolution of 25 mm and a protective height of 16 mm, with a maximum scanning range of 8 meters. The device operates with beam coding and external device monitoring (EDM) capabilities to ensure functional safety. It utilizes an M12, 8-pin male connector for interface connectivity. The unit supports safe operating modes including safeguarding and presence sensing, complying with relevant safety standards for machine guarding applications.

Feature Summary

• Beam coding technology ensures reliable identification and prevents interference from adjacent safety devices
• External Device Monitoring (EDM) function allows verification of connected safety relay or controller status
• Robust housing design suitable for harsh industrial manufacturing conditions

Applications

• Personnel safeguarding at press brakes and stamping machines
• Access protection for injection molding equipment
• Safety monitoring around automated assembly lines

Procurement Notes

Verify the specific订货代号 (Order Code) matches the required protective height and scanning range configuration. Confirm that the M12 connector type aligns with existing cabling infrastructure. Ensure the device version supports the necessary safety integrity level for the target application. Cross-reference the product documentation for any regional certification requirements.

Selection Notes

Select this model based on the required 25 mm resolution for personnel protection. Evaluate the 8-meter scanning range against the physical dimensions of the hazard zone. Consider the M12 interface compatibility with control systems. Verify that the beam coding feature is sufficient to prevent cross-talk in dense installation layouts compared to other series options.

Part Context

This component belongs to the DL100 series of safety light curtains manufactured by SICK. The series is engineered for high-performance machine safety applications requiring precise detection and robust reliability. The DL100 models are characterized by their compact design and flexible configuration options for various industrial safety scenarios.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
