1117018

Overview

The SICK part number 1117018 corresponds to the GTB6-P4211, a direct reflection photoelectric sensor. It features a PinPoint LED light source with a wavelength of 650 nm and a maximum detection range of 20 mm to 950 mm against a 90% diffuse reflector. The device utilizes a square housing measuring 20 mm x 50 mm x 39 mm and includes an adjustment knob for setup. It operates on a DC power supply voltage ranging from 10 V to 30 V and provides a PNP switching output.

Feature Summary

• Direct reflection sensing principle with background suppression capability
• PinPoint LED technology for precise spot targeting
• Adjustable sensitivity via mechanical control knob

Applications

• Object detection in automated assembly lines
• Position verification in packaging machinery
• Presence monitoring in industrial safety systems

Procurement Notes

Verify the specific connector type and cable length requirements against the official datasheet before ordering. Confirm that the PNP output logic matches the control system interface. Ensure the mounting hardware is compatible with the square housing dimensions. Cross-reference the订货代号 (Order Code) if available in regional catalogs to ensure correct variant selection.

Selection Notes

Select this model when a compact form factor is required for tight installation spaces. The PinPoint LED feature makes it suitable for detecting small targets or precise positioning tasks. Consider the 950 mm detection range as the operational limit for high-reflectivity objects. Evaluate the mechanical adjustment method if electronic teaching-in is not supported by the controller.

Part Context

This component belongs to the GTB10 series of photoelectric sensors manufactured by SICK. The series is designed for general industrial automation applications requiring reliable object detection. The GTB6-P4211 shares the same housing design and core optical principles as other variants in the family, differing primarily in electrical connections and specific output configurations.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
