Overview

The SICK model 1119560 is an incremental encoder belonging to the DFS60 series, designed for motion control applications. It features a robust mechanical design suitable for industrial environments and provides precise rotational position feedback. The unit supports configurable electrical zero pulse widths of 90°, 180°, or 270° relative to a pulse period. Mechanical zero pulse width is programmable from 1° to 359°. The device operates with a nominal load at average ambient temperatures up to 40°C and utilizes a half-shell servo clamp or small servo clamp for mounting requirements.

Feature Summary

• Configurable electrical zero pulse width options including 90, 180, and 270 degrees relative to the pulse period.
• Programmable mechanical zero pulse width ranging from 1 to 359 degrees relative to shaft revolution.
• Supports mounting via half-shell servo clamp or small servo clamp mechanisms.

Applications

• Motion control systems requiring precise rotational feedback
• Industrial automation machinery
• Servo drive integration

Procurement Notes

Verify the specific part number 1119560 against official SICK documentation to confirm exact technical specifications and compatibility. Ensure that the required mounting method aligns with available half-shell or small servo clamp options. Cross-reference the configurable zero pulse settings with system requirements before procurement to avoid integration issues.

Selection Notes

Select this incremental encoder when precise angular position feedback is required for motion control tasks. Consider the programmability of the mechanical and electrical zero pulses to match existing system synchronization needs. Evaluate the mounting constraints to determine if half-shell or small servo clamp interfaces are suitable for the installation environment.

Part Context

This component is part of the DFS60 series of incremental encoders manufactured by SICK. The series is engineered for motion control applications within industrial automation sectors. The DFS60 line emphasizes reliability and precision in rotational measurement tasks.

Replacement Considerations

Consult official SICK substitution guides for verified replacement part numbers. Generic equivalents may not support the specific programmable zero pulse configurations or mounting interfaces required for seamless integration.

FAQ

What are the available electrical zero pulse width settings?

The electrical zero pulse width can be configured to 90°, 180°, or 270° relative to a pulse period.

How is the mechanical zero pulse width defined?

The mechanical zero pulse width is programmable from 1° to 359° relative to a mechanical revolution of the shaft.
