1121586

Overview

The SICK part number 1121586 corresponds to the AHM36A-SCQC000A30, an absolute encoder from the AHS/AHM36 series. This component integrates a measuring wheel and mechanical assembly designed for position tracking applications. It features a robust construction suitable for industrial environments, providing reliable data transmission for motion control systems.

Feature Summary

• Integrates optical single-turn measurement with mechanical multi-turn system
• Designed for precise position monitoring in automation machinery
• Includes dedicated mounting flange and measuring wheel mechanics

Applications

• Position tracking on automated guided vehicles
• Height adjustment mechanisms in lifting equipment
• Linear axis positioning in industrial manufacturing systems

Procurement Notes

Verify the complete part number AHM36A-SCQC000A30 against official SICK documentation to ensure correct configuration. Confirm that the specific mounting interface and cable length requirements match the intended application setup before finalizing the order.

Selection Notes

Select this model when mechanical integration of a measuring wheel is required rather than a standard rotary shaft encoder. Ensure the application demands high resolution for both single-turn and multi-turn position data within the specified mechanical constraints of the AHM36 housing design.

Part Context

This component belongs to the AHM36 series of absolute encoders manufactured by SICK. The series is engineered for demanding industrial conditions, combining optical and mechanical technologies to deliver accurate position feedback for complex motion control tasks across various automation sectors.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
