1121598

Overview

The SICK part number 1121598 corresponds to the Visionary-S CX industrial 3D vision sensor. This device utilizes structured light illumination combined with color camera technology to generate real-time color depth images based on stereo vision principles. It is designed for fixed installation in factory automation environments, offering high resolution and rapid image acquisition speeds. The unit features a rugged housing suitable for industrial use and connects via a Gigabit Ethernet interface for data output.

Feature Summary

• Generates real-time color depth images by combining structured light with color camera technology
• Provides direct output of raw color and depth values through a Gigabit Ethernet interface
• Capable of operating reliably in absolute darkness or under strong ambient sunlight up to 40 klx
• Supports configuration and setup using SOPAS ET software

Applications

• Robotics guidance and manipulation
• Internal logistics and material handling
• Quality assurance tasks in production lines

Procurement Notes

Verify the specific suffix code (e.g., short or long heat sink variant) against the required operating temperature range. Confirm that the Gigabit Ethernet interface aligns with the host system's network infrastructure. Ensure the IP67 enclosure rating meets the environmental protection requirements of the intended installation site.

Selection Notes

Select this model when direct access to raw 3D color data is required without onboard processing. Choose the short heat sink version for ambient temperatures up to 40°C and the long heat sink version for environments reaching 50°C. This sensor is suitable for applications demanding high spatial resolution and fast frame rates within a fixed mounting scenario.

Part Context

This component belongs to the Visionary-S series of 3D snapshot sensors from SICK. The series leverages stereoscopic vision to deliver precise depth information. The CX variant specifically focuses on streaming unprocessed data for flexible integration into custom software solutions or external processing units.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation.
