Overview

The SICK DFS60B-S4EA05000 is an incremental encoder from the DFS60 series, designed for full shaft mounting applications. It features a solid shaft with a 10 mm diameter and provides an HTL output signal. The device operates at a supply voltage of 32V and delivers a resolution of 5000 pulses per revolution (ppr). It is rated for a maximum operating temperature of 100 °C and offers an IP65 protection class.

Feature Summary

• Provides high-resolution position feedback via HTL output signals
• Designed for robust industrial environments with IP65 ingress protection
• Supports full shaft mounting configuration for direct mechanical integration

Applications

• Industrial automation machinery requiring precise rotational position monitoring
• Conveyor systems utilizing full shaft mounting configurations
• Equipment operating in environments with moderate thermal stress up to 100 °C

Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to ensure compatibility with required interface protocols and shaft dimensions. Confirm that the HTL output signal type matches the receiving controller's input specifications. Ensure the installation environment remains within the specified 100 °C thermal limit and maintains IP65 integrity during operation.

Selection Notes

Select this model when a solid shaft encoder with 10 mm diameter is required for full shaft mounting. The HTL output is suitable for controllers supporting this specific signal standard. Consider the 5000 ppr resolution for applications needing detailed rotational data. Verify that the 32V supply voltage aligns with the system power architecture before procurement.

Part Context

This component belongs to the SICK DFS60 series of incremental encoders. The series is characterized by compact design and versatility for various industrial sensing tasks. The DFS60B variant specifically denotes the housing and connection type within this family, distinguishing it from other shaft or interface options available in the broader DFS60 lineup.

Replacement Considerations

Consult official SICK documentation for cross-references. No public substitute part numbers are confirmed for this specific configuration.
