1130201

Overview

The SICK GL2S-N1312 is a retro-reflective photoelectric sensor featuring a square housing measuring 7.7 mm x 21.8 mm x 13.5 mm. It utilizes a visible red PinPoint LED light source with a wavelength of 640 nm to generate a focused light spot, specified as Ø 11 mm at a distance of 250 mm. The device operates within a detection range of 0.02 m to 3 m when paired with the PL40A reflector. It is designed for precise object detection in automated environments requiring compact integration and stable optical performance.

Feature Summary

• PinPoint LED technology provides a highly focused light spot for accurate detection of small targets
• Compact square housing design facilitates installation in space-constrained machinery applications
• Visible red light source allows for easy visual alignment and positioning during setup

Applications

• Automated material handling systems
• Packaging machine safety monitoring
• Industrial process automation

Procurement Notes

Verify that the specific order includes the required PL40A retro-reflective sheet, as it is essential for achieving the stated maximum detection range. Confirm interface compatibility with existing control systems before procurement. Ensure environmental conditions remain within the operational limits defined in the technical documentation.

Selection Notes

Select this model for applications requiring high precision on small objects due to the PinPoint LED characteristic. Consider the compact dimensions for tight mounting spaces. Evaluate the need for visible light for alignment purposes against potential interference from ambient lighting conditions in the installation area.

Part Context

This component belongs to the GL2S series of photoelectric sensors manufactured by SICK AG. The series focuses on providing reliable sensing solutions for industrial automation tasks. The GL2S-N1312 variant specifically addresses needs for compact form factors and precise detection capabilities using retro-reflective technology.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
