1131450

Overview

The SICK part number 1131450 corresponds to the FTMG-ESD25AXX, an industrial flow meter designed for measuring liquid flow rates in piping systems. This device features a DN 25 nominal diameter with G 1 process connections compliant with DIN ISO 228-1 standards. It supports advanced communication protocols including OPC UA, MQTT, and REST API, facilitated by an integrated web server. The unit utilizes M12 x 1.8 pin X-coded circular connectors for interface connectivity. It provides analog output signals alongside digital capabilities and maintains IP65 and IP67 protection ratings for robust operation in demanding industrial environments.

Feature Summary

• Supports advanced industrial communication protocols including OPC UA and MQTT
• Features an integrated web server for configuration and monitoring via REST API
• Provides flexible signal outputs combining analog and digital transmission modes

Applications

• Industrial process automation requiring precise liquid flow measurement
• Smart factory implementations utilizing IoT connectivity for data integration
• Hydraulic and pneumatic system monitoring applications

Procurement Notes

Verify the specific suffix codes on the ordering label to confirm protocol support and connection type. Ensure compatibility with existing network infrastructure for OPC UA or MQTT integration. Confirm process connection dimensions match the target piping system specifications before installation.

Selection Notes

Select this model when advanced web-based diagnostics and modern industrial IoT protocols are required. Consider alternative variants if standard IO-Link communication suffices for the application. Evaluate environmental conditions to ensure the IP65/IP67 rating meets site requirements.

Part Context

This component belongs to the FTMG series of flow meters manufactured by SICK. The series offers various nominal diameters and connection options to suit different pipeline sizes. The ESD variant specifically denotes models equipped with Ethernet-based smart fieldbus interfaces for enhanced data exchange capabilities.

Replacement Considerations

Public confirmed substitute part numbers: None identified.
