1133091

Overview

The SICK model 1133091 is a safety light curtain belonging to the C4MT series. It features a resolution of 40 mm and a protective height of 600 mm, designed for personnel protection. The device utilizes a red LED light source with a wavelength of 650 nm. It supports PNP switching outputs and includes an M12 connector interface for power and signal transmission. The unit operates within a standard ambient temperature range and provides IP65 ingress protection against dust and water jets.

Feature Summary

• Provides reliable personnel protection through precise object detection via a multi-beam optical field.
• Integrates external device monitoring (EDM) capabilities to ensure functional safety integrity.
• Features robust housing construction suitable for demanding industrial environments.

Applications

• Machine guarding on automated manufacturing equipment
• Protection zones around robotic work cells
• Safety barriers for press machines and injection molding units

Procurement Notes

Verify the specific order number against the manufacturer's current product portfolio to confirm availability and technical specifications. Ensure compatibility with existing safety controllers and mounting hardware. Check for any regional certification requirements or updated documentation versions prior to finalizing procurement orders.

Selection Notes

Select this model based on the required protective height of 600 mm and the 40 mm resolution necessary for safeguarding against hand or finger intrusion. Confirm that the PNP output type matches the input logic of the connected safety PLC. Evaluate the installation space constraints to ensure the emitter and receiver dimensions fit the machine opening.

Part Context

This component is part of the C4MT safety light curtain family from SICK, Inc., engineered for industrial safety applications. The series is characterized by compact design and high reliability in detecting intrusions into hazardous areas. It serves as a critical safety interface between machinery operation and operator presence.

Replacement Considerations

Consult official SICK substitution guides for verified equivalent models. Ensure any replacement maintains identical resolution, protective height, and safety performance levels. Verify electrical interface compatibility before swapping components.
