Overview

The SICK model 1135070 is an incremental encoder from the DFS60 series, designed for motion control applications. It features a robust mechanical design suitable for industrial environments. The unit provides precise rotational position and speed feedback through standard incremental output signals. Key technical specifications include a maximum revolution range of 6000 rpm and an electrical zero pulse width that can be configured to 90°, 180°, or 270°. The mechanical zero pulse width is programmable between 1° and 359°. The device operates with a mean time to dangerous failure (MTTFd) of 300 years under nominal load conditions at an average ambient temperature of 40°C, calculated according to EN ISO 13849-1 standards.

Feature Summary

• Configurable electrical zero pulse width allows adaptation to specific system synchronization requirements.
• Programmable mechanical zero pulse width enables precise alignment relative to the shaft's mechanical revolution.
• High reliability indicated by a long mean time to dangerous failure rating for safety-related parameter assessment.

Applications

• Servo clamp mounting integration
• Small servo clamp mounting integration
• Motion control systems requiring incremental feedback

Procurement Notes

Verify the exact订货代号 (order code) associated with part number 1136756 when sourcing. Confirm interface compatibility and mounting requirements against the specific machine design. Ensure ambient temperature conditions do not exceed the operational limits defined in the technical data sheet. Check for required accessories such as coupling elements or mounting hardware not included in the standard delivery.

Selection Notes

Select this model based on the need for configurable zero pulses and high MTTFd ratings. Compare the maximum revolution range and interface options against other DFS60 variants. Consider the mounting type, such as half-shell servo clamp or small servo clamp, during the selection process to ensure mechanical fit. Evaluate the programmability of the zero pulse widths to match control system constraints.

Part Context

This component belongs to the DFS60 incremental encoder family from SICK. The series is characterized by compact design and versatility for various motion control tasks. Models within this family share common mounting interfaces and electronic principles but differ in resolution, interface types, and mechanical dimensions. The DFS60 series supports both standard and customized configurations for industrial automation.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult SICK technical support for cross-referencing compatible models with similar specifications.
