1136307

Overview

The SICK model 1136307 is a component of the Lector62x series, specifically identified as an image-based code reader designed for reliable detection of 1D, 2D, and DPM codes. This compact unit utilizes advanced decoding algorithms to ensure high throughput even with highly reflective or contaminated codes. It features a variable illumination concept with bi-color LEDs to maintain performance in changing light conditions. The device supports automated setup wizards for efficient commissioning and includes parameter backup capabilities via microSD card to minimize downtime during replacement.

Feature Summary

• Intelligent decoding algorithms enable high throughput processing of challenging codes including those that are highly reflective or contaminated.
• Variable illumination concept utilizing bi-color LEDs ensures reliable reading performance under varying ambient light conditions and on reflective surfaces.
• Automated setup wizard facilitates faster and more cost-effective commissioning processes.
• Parameter backup functionality stored on a microSD card allows for quick device replacement with minimal production downtime.

Applications

• Reliable identification of 1D, 2D, and DPM codes on production lines
• Reading lasered or dot-peened codes with low contrast levels
• Code identification in environments with contamination or poor code quality
• Applications requiring compact form factors due to tight space constraints

Procurement Notes

Verify the specific variant suffix against the official SICK product documentation to ensure compatibility with required interface protocols and mounting configurations. Confirm that the selected model meets all necessary environmental ratings for the intended installation location. Cross-reference the ordering number with current technical datasheets to validate feature sets such as illumination type and connector orientation before finalizing procurement decisions.

Selection Notes

Choose this model when application requirements demand robust performance on difficult-to-read codes such as DPM marks or highly reflective surfaces. The compact housing design makes it suitable for installations where spatial limitations restrict the use of larger readers. Consider this option if rapid commissioning through automated wizards and simplified maintenance via parameter backup are critical operational priorities for the production environment.

Part Context

This component belongs to the Lector62x family of image-based code readers manufactured by SICK. The series is engineered for industrial automation tasks requiring precise and reliable data capture. These devices integrate advanced optical and electronic technologies to support continuous operation in demanding manufacturing settings, providing essential input for traceability and quality control systems.

Replacement Considerations

Consult official SICK documentation to identify direct substitute part numbers within the Lector62x series. Ensure any replacement maintains identical interface specifications and mechanical dimensions to guarantee seamless integration into existing setups without requiring structural modifications.
