Overview

The SICK GL2S-N1312 is a retro-reflective photoelectric sensor with a square housing measuring 7.7 mm x 21.8 mm x 13.5 mm. It utilizes a visible red PinPoint LED light source at 640 nm wavelength to project an average spot size of Ø 11 mm at 250 mm distance. The device operates within a detection range of 0.03 m to 2.5 m when paired with the PL40A reflector, achieving a maximum range of 3 m under specific conditions. It features Cd-043 connection type and offers an average service life of 100,000 hours at +25 °C.

Feature Summary

• PinPoint LED technology for precise spot projection
• Compact square housing design for space-constrained installations
• Retro-reflective operating principle for reliable object detection

Applications

• Automated material handling processes
• Industrial machine monitoring
• Logistics automation systems

Procurement Notes

Verify the exact ordering code against official SICK documentation to ensure correct configuration. Confirm that the required reflector, such as the PL40A or PL20A, is included in the procurement scope. Check technical drawings for mechanical fitment requirements before finalizing orders. Ensure environmental conditions align with the specified operational parameters.

Selection Notes

Select this model for applications requiring high precision due to its PinPoint LED characteristics. Consider the compact dimensions when integrating into tight spaces. Evaluate the detection range requirements against the 0.03 m to 2.5 m specification. Verify compatibility with existing control interfaces and mounting structures.

Part Context

This component belongs to the GL2S series of photoelectric sensors from SICK. The series focuses on providing intelligent sensor solutions for digitalizing industry processes. These sensors are designed to enhance transparency and availability in material handling workflows through reliable hardware integration.

Replacement Considerations

Consult official SICK substitution guides for verified compatible models. Ensure replacement units maintain identical electrical connections and mechanical dimensions. Verify that optical performance metrics meet the original application requirements.
