1144026

Overview

The SICK model 1144026 is a safety light curtain component belonging to the M2000 Standard series. It functions as a protective device featuring beam encoding and external device monitoring (EDM) capabilities. The unit utilizes an M12, 8-pin male connector for interface connectivity. Key operational parameters include a resolution of 25 mm and a scanning range of 170 mm. These specifications define its role in personnel protection within automated industrial environments.

Feature Summary

• Integrated beam encoding technology ensures reliable signal identification and interference rejection.
• Supports External Device Monitoring (EDM) for comprehensive safety circuit verification.
• Utilizes standardized M12 connector interfaces for straightforward system integration.

Applications

• Personnel protection at hazardous machine zones
• Safety guarding for automated manufacturing equipment
• Integration into safety circuits requiring EDM functionality

Procurement Notes

Verify the specific variant suffix against the official SICK product catalog to confirm the exact connector type and cable length. Ensure compatibility with the intended safety controller regarding voltage levels and signal logic. Cross-reference the ordering number with current technical documentation to validate regional certification requirements and mounting accessories.

Selection Notes

Select this model based on the required 25 mm resolution and 170 mm scanning range for the specific application zone. Confirm that the M12 interface aligns with existing control system wiring standards. Evaluate whether the integrated beam encoding and EDM features meet the necessary safety integrity level for the machinery being protected.

Part Context

This component is part of the SICK M2000 Standard safety light curtain family. The series provides modular solutions for machine safety, emphasizing ease of installation and robust performance. The M2000 line supports various resolutions and ranges to accommodate different safety distances and hazard assessments.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material. Consult official SICK documentation for legacy replacements or updated series equivalents.
