Product Detailed Parameters
- Description：Interconnect Misc
- Series：*
- Mfr：Phoenix Contact
- Package：Bulk
Download product information
Overview
Phoenix Contact part number 1215394 is a COMBICON MC 1,5/ 6-GF-3,81-LR PCB header. It features a 6-position configuration with a 3.81 mm pitch and green housing. Rated for 8 A nominal current and 160 V voltage (III/2), it utilizes wave soldering mounting. The connector employs a lock-and-release system for secure attachment to mating COMBICON plugs.
Feature Summary
- Lock-and-release locking mechanism ensures secure connection between the PCB header and mating plug components.
- Designed for wave soldering mounting methods to facilitate automated printed circuit board assembly processes.
Applications
- Industrial control cabinet signal distribution
- Automation equipment interface connections
- Process heating system wiring
Procurement Notes
Verify the complete part number includes the suffix -LR to confirm the specific lock-and-release feature and linear pinning layout. Ensure compatibility with the corresponding COMBICON MC 1,5 series mating plugs before procurement.
Selection Notes
Select this component when a 6-position PCB header with a 3.81 mm pitch is required. The lock-and-release feature distinguishes it from standard headers, providing enhanced mechanical stability during operation in industrial environments.
Part Context
This component belongs to the COMBICON Connectors S product line. It serves as the PCB-side counterpart to the COMBICON MC 1,5 series plug-in connectors, enabling modular electrical interconnections within Phoenix Contact's standardized terminal block ecosystem.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Consult manufacturer resources for potential obsolescence management or alternative series recommendations if necessary.
FAQ
What is the rated surge voltage for this PCB header?
The rated surge voltage is 2.5 kV under overvoltage category III/2 conditions.
Does this connector support double-wire connection?
No, the technical data specifies single wire connection capability per position for rigid and flexible wires within the stated cross-section range.
