Overview

The Phoenix Contact model 1424023 is a HC-B 16-S-PT/M1NC plug housing component designed for power applications. It features a B16 series size with 16 poles plus PE, utilizing push-in connection technology. The unit supports rigid conductors from 0.14 mm² to 2.5 mm² and flexible conductors within the same range. Rated at 500 V nominal voltage and 16 A current, it complies with IEC 61984 standards. Dimensions are 34 mm width, 34.4 mm height, and 84 mm length, with a 77.5 mm horizontal hole spacing.

Feature Summary

• Push-in connection technology for rapid assembly without tools
• Polarity-fixed contact element design ensuring secure orientation
• Compliant with IEC 61984 standard for switchless capacity connectors
• Suitable for mounting in enclosures with IP54 protection or higher

Applications

• Power distribution systems requiring reliable plug connections
• Industrial control cabinet wiring assemblies
• Machinery integration where tool-free maintenance is required
• Electrical installations adhering to IEC 61984 standards

Procurement Notes

Verify the specific ordering suffix matches the required configuration, as variations exist within the HC-B series. Confirm that the application environment meets the IP54 enclosure requirement specified for proper operation. Ensure compatibility with corresponding female contacts and mating plugs before finalizing procurement orders.

Selection Notes

Select this component when a 16-pole plus PE power connection is necessary. The push-in interface eliminates the need for screwdrivers during installation. Verify conductor cross-sections fall within the 0.14 mm² to 2.5 mm² range. Consider the physical dimensions and hole spacing for panel cutout requirements.

Part Context

This part belongs to the HC-B series of plug housings manufactured by Phoenix Contact. It serves as a fixed-polarity contact element for power applications. The B16 size designation indicates its specific form factor and pole count capability within the broader product family.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
