Overview

The Phoenix Contact FL SWITCH 2206C-2FX (Part No. 1456045) is a managed industrial Ethernet switch from the Managed Switch 2000 series. It features six RJ45 ports supporting 10/100 MBit/s and two SC multimode fiber optic ports operating at 100 Mbps full duplex. The device operates within an ambient temperature range of -40 °C to 70 °C and accepts a supply voltage of 9 V DC to 57 V DC. It provides IP20 protection, supports PROFINET Conformance Class B, and includes coated PCBs for harsh environments.

Feature Summary

• Supports wide temperature operation with coated printed circuit boards for enhanced durability in industrial settings.
• Certified development process according to IEC 62443-4-1 and product certification under IEC 62443-4-2 standards.
• Enables PROFINET communication with Conformance Class B support for deterministic data exchange.

Applications

• Industrial automation networks requiring robust Ethernet connectivity
• PROFINET infrastructure deployment
• Harsh environment monitoring systems

Procurement Notes

Verify that the specific part number 1456045 matches the required port configuration and environmental ratings. Confirm compatibility with existing power supplies within the 9 V DC to 57 V DC range. Ensure installation meets IP20 requirements and DIN rail mounting specifications. Check for necessary firmware updates to maintain IEC 62443 compliance.

Selection Notes

Select this model when PROFINET Class B performance is required alongside extended temperature capabilities. Consider the 10/100 Mbps copper interface limitations compared to Gigabit alternatives if higher bandwidth is needed. Verify that the SC multimode fiber interfaces align with the existing cabling infrastructure wavelength and distance requirements.

Part Context

This component belongs to the FL SWITCH 2000 series, designed specifically for industrial applications. It differs from consumer-grade switches by offering wider temperature ranges, rugged housing materials like fiber-reinforced polycarbonate, and specialized certifications for industrial security and reliability standards.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Users should consult official Phoenix Contact resources for cross-reference information or newer generation equivalents within the Managed Switch portfolio.
