1462723

Overview

Phoenix Contact part number 1462723 is a COMBICON MC 1,5/ 8-GF-5,08 PCB header. It features eight positions with a 5.08 mm pitch and supports a nominal current of 8 A at a rated voltage of 160 V. The component utilizes wave soldering for mounting and incorporates a lock-and-release threaded flange system for secure attachment to mating connectors. The housing is green, and the contact surface is tin-plated.

Feature Summary

• Lock-and-release locking system ensures secure mechanical connection between header and plug.
• Threaded flange mounting method provides stable fixation on printed circuit boards.
• Standard pin connector pattern alignment facilitates straightforward integration into assembly workflows.

Applications

• Industrial automation control systems
• Signal distribution in electronic enclosures
• Machine building interconnects

Procurement Notes

Verify the specific ordering suffix matches the required configuration. Confirm that the pin layout and mounting style align with the target PCB design. Ensure environmental ratings meet operational requirements before finalizing procurement orders.

Selection Notes

Select this component when an eight-position interface with a 5.08 mm pitch is required. The lock-and-release feature is suitable for applications needing reliable connector retention. Verify compatibility with mating plugs from the same product family.

Part Context

This component belongs to the COMBICON Connectors S product line. It serves as a standard PCB header within Phoenix Contact's modular connector portfolio. The series is designed for versatile signal and low-power applications in industrial environments.

Replacement Considerations

Consult official cross-reference tools for compatible alternatives. Verify dimensional and electrical compatibility before substituting with components from other manufacturers.

FAQ

What is the locking mechanism type?

The component uses a lock-and-release locking system with a threaded flange for secure mounting.

Is the contact surface tin-plated?

Yes, the contact surface specification indicates tin plating.
