1467180

Overview

The Phoenix Contact part number 1467180 identifies a fixed connector from the PT 1,5/14-5,0-V product series within the COMBICON Terminals S line. This component features 14 positions arranged in a single row with a 5 mm pitch. It utilizes screw connections with wire protection for conductor attachment and is designed for wave soldering mounting. The unit supports a rated current of 17.5 A and operates at rated voltages up to 400 V (III/2) or 630 V (II/2). The housing is green, and it accepts rigid or flexible wires ranging from 0.2 mm² to 2.5 mm².

Feature Summary

• Screw connection technology incorporating wire protection mechanisms
• Single-row configuration with 14 positions and 5 mm pitch
• Designed for wave soldering installation on printed circuit boards

Applications

• Industrial control cabinet wiring
• Signal distribution in automation systems
• Power supply connections for low-voltage equipment

Procurement Notes

Verify the complete part number including suffixes against official Phoenix Contact documentation to ensure correct pin spacing and connection type. Confirm that the specific voltage category and current rating requirements match the application environment. Check for any recent updates to the product datasheet regarding material compliance or RoHS status before finalizing procurement specifications.

Selection Notes

Select this component when a fixed PCB terminal with screw connections and wire protection is required. Ensure the available space accommodates the 5 mm pitch and single-row layout. Verify that the wire gauge range of 0.2 mm² to 2.5 mm² matches the cable specifications. Consider the wave soldering mounting method during the PCB design phase to ensure compatibility with the manufacturing process.

Part Context

This component belongs to the PT 1,5/..-V series of COMBICON Terminals S. The series is characterized by its compact design and reliable screw connection technology. These terminals are widely used in industrial applications requiring secure and durable electrical connections on printed circuit boards. The product line emphasizes ease of assembly and maintenance through standardized dimensions and connection methods.

Replacement Considerations

Consult official Phoenix Contact substitution guides for verified alternative part numbers. Ensure any replacement maintains identical pitch, current rating, and connection technology. Do not assume cross-compatibility with other terminal series without verifying technical specifications.
