1467239

Overview

The Phoenix Contact 1467239 is a PCB terminal block designed for secure electrical connections in industrial control environments. It features a nominal current rating of 24 A and supports a rated voltage of 800 V. The component utilizes a screw connection method with a pitch of 5.08 mm, accommodating conductors within a cross-section range of 0.5 to 2.5 mm². Constructed from polycarbonate (PC) housing material, it offers UL 94 V-0 flame resistance. The device includes a marking field area for identification purposes and is designed for DIN rail mounting compatibility via associated accessories.

Feature Summary

• Screw connection mechanism ensures reliable conductor fixation without soldering requirements.
• Polycarbonate housing provides high mechanical stability and flame retardant properties.
• Integrated marking field allows for clear circuit identification and maintenance.

Applications

• Industrial control cabinet wiring
• Signal distribution in automation systems
• Power supply connection points

Procurement Notes

Verify the specific ordering code against the manufacturer's official datasheet to ensure correct pin configuration and accessory compatibility. Confirm that the required auxiliary components, such as bridging elements or end brackets, are included in the procurement list if necessary for the specific assembly design.

Selection Notes

Select this component based on the required current carrying capacity and voltage isolation levels for the target application. Ensure the conductor cross-section matches the specified acceptance range to guarantee proper contact pressure. Consider the environmental conditions, such as temperature ratings, to verify compliance with operational standards.

Part Context

This terminal block belongs to the Phoenix Contact UK series, which is widely used in European industrial standards. The series is characterized by its compact design and high density capabilities, allowing for efficient space utilization in control panels. It complements other components in the same product family for modular system expansion.

Replacement Considerations

Direct replacements must match the 5.08 mm pitch and 24 A current rating. Verify physical dimensions and mounting hole patterns to ensure compatibility with existing PCB layouts or DIN rail adapters. Consult the manufacturer's substitution guide for equivalent part numbers with identical technical specifications.

FAQ

What is the maximum conductor cross-section supported by this terminal block?

The terminal block supports solid and stranded conductors with a cross-section between 0.5 mm² and 2.5 mm².

Is this component suitable for high-voltage applications?

Yes, it has a rated voltage of 800 V, making it suitable for standard industrial control voltages.
