1473151-1

$7.52

Description：CONN EDGE DUAL FMALE 70POS 0.100
Series：-
Mfr：TE Connectivity AMP Connectors
Package：Tray

SKU:6eee3b3c50fc Category: Edgeboard Connectors Brand: TE Connectivity AMP Connectors

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

1473151-1 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists TE Connectivity AMP Connectors. Its product description is CONN EDGE DUAL FMALE 70POS 0.100. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 1473151-1

Description：CONN EDGE DUAL FMALE 70POS 0.100
Series：-
Mfr：TE Connectivity AMP Connectors
Package：Tray
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：-
Number of Positions：70
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.100" (2.54mm)
Read Out：Dual
Features：-
Mounting Type：Surface Mount
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：-
Contact Type：-
Color：-
Flange Feature：Flush Mount, Top Opening, Unthreaded, 0.130" (3.30mm) Dia
Operating Temperature：-20°C ~ 80°C

Edgeboard Connectors datasheet and documents for 1473151-1

1473151-1

Edgeboard Connectors Overview

The 1473151-1 is a Card Edge Power Connector manufactured by TE Connectivity AMP Connectors. It features a dual-edge configuration with 70 positions and a 2.54 mm (0.1 in) centerline. The connector includes 70 signal positions and 0 dual power positions. Contact surfaces are gold-plated brass. Designed for board-to-board applications, it supports power and signal transmission within the Power & Signal category.

Edgeboard Connectors Feature Summary

Dual-edge card edge design for secure board-to-board connection
Gold-plated contacts ensure reliable signal integrity
Standardized 2.54 mm centerline spacing

Edgeboard Connectors Applications

Board-to-board interconnects
Power and signal distribution systems

Edgeboard Connectors Procurement Notes

Verify the specific datasheet version and RoHS compliance status directly with TE Connectivity or authorized distributors before procurement. Confirm that the 70-position dual-edge specification matches the target PCB footprint requirements. Ensure storage conditions adhere to manufacturer guidelines to maintain contact surface quality.

Edgeboard Connectors Selection Notes

Select this component when a high-density 70-position interface is required with a standard 2.54 mm pitch. The dual-edge geometry provides mechanical stability for vertical mating. Gold plating is suitable for environments requiring low contact resistance and corrosion resistance. Validate that the application does not require additional shielding or filtering features not present in this basic connector type.

Edgeboard Connectors Part Context

This part belongs to the AMP Connectors line of card edge solutions. It serves as a standardized interface for connecting circuit boards in electronic assemblies. The dual-edge format allows for increased pin count within a compact profile compared to single-edge variants.
