1482527

Overview

The Phoenix Contact 1482527 is a circular connector assembly designed for industrial applications. It features a 4-position configuration with a male plug housing and female socket contacts. The unit utilizes push-in spring connection technology for rapid wiring. It is rated for 30V AC/DC and supports cable diameters between 3.5 mm and 5.5 mm. The connector operates within a temperature range of -25°C to 85°C and offers IP65 and IP67 ingress protection ratings.

Feature Summary

• Push-in spring connection mechanism enables tool-free wire termination
• Robust metal housing constructed from zinc die-cast material
• High ingress protection suitable for demanding industrial environments
• Standard A-coded pin assignment for reliable signal identification

Applications

• Industrial sensor and actuator wiring networks
• Control cabinet interconnection systems
• Automated machinery power distribution
• Process control instrumentation interfaces

Procurement Notes

Verify the specific variant suffix against the manufacturer datasheet to ensure compatibility with required cable diameter ranges and coding standards. Confirm that the push-in termination method aligns with the intended wire gauge specifications for the target application environment.

Selection Notes

Select this component when a robust, shielded or unshielded circular connector is required for harsh industrial conditions. Ensure the operating voltage does not exceed 30V AC/DC. Verify that the M8 form factor fits the available panel space and that the push-in termination method is compatible with the selected wire types.

Part Context

This part belongs to the SACC-M series of circular connectors from Phoenix Contact. The series provides standardized metric connector solutions for data and power transmission in automation technology. These components are engineered for high durability and secure mechanical locking in mobile and fixed installations.

Replacement Considerations

Cross-reference with other Phoenix Contact M8 circular connector assemblies sharing identical 4-position layouts and push-in termination styles. Verify that substitute parts maintain matching IP65/IP67 ratings and compatible cable entry dimensions.
