1487460

Overview

Phoenix Contact part number 1487460 is a COMBIFIX plug-in element designed for industrial signal and data transmission applications. This component features a fixed polarity design with four poles and a standard pitch of 5.2 mm, ensuring secure mating within compatible connector systems. It utilizes push-in spring connection technology to facilitate rapid tool-free wiring termination. The unit supports flexible wire cross-sections ranging from 0.14 mm² to 2.5 mm², accommodating AWG sizes 28 through 12. Rated for a nominal current of 24 A and a rated voltage of 500 V, the device provides reliable electrical continuity in control cabinet environments.

Feature Summary

• Push-in spring connection technology enables fast, tool-free wiring termination without requiring separate crimping or screwdriver tools.
• Fixed polarity design ensures correct orientation during mating, preventing reverse connection errors in multi-pole assemblies.
• Compliant with IEC 61984 standards for COMBI plugs, allowing safe connection and disconnection under no-load or no-voltage conditions.

Applications

• Industrial automation control cabinets
• Signal distribution networks
• Data transmission interconnections

Procurement Notes

Verify that the specific order quantity matches the manufacturer's minimum packaging requirements before finalizing the purchase. Confirm compatibility with the intended housing or carrier frame to ensure proper mechanical fit. Check technical documentation for any recent updates regarding insulation material specifications or environmental ratings. Ensure all mating components adhere to the same IEC 61984 standard for reliable system integration.

Selection Notes

Select this model when a four-pole configuration with a 5.2 mm pitch is required for signal or data lines. Choose the push-in variant if tool-free assembly speed is a priority over traditional screw connections. Verify that the operating environment does not exceed the rated voltage and current limits. Ensure the application allows for connection only under de-energized conditions as per safety standards.

Part Context

This component belongs to the Phoenix Contact COMBIFIX series, which provides modular plug-in solutions for industrial connectivity. These elements are designed to be inserted into corresponding housings or carrier frames to create complete connector assemblies. The series emphasizes standardized dimensions and reliable performance across various automation sectors.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
