Product Detailed Parameters
- Description：Interconnect Misc
- Series：*
- Mfr：Phoenix Contact
- Package：Bulk
Download product information
Overview
Phoenix Contact part number 1488686 is an AC charging cable belonging to the CHARX connect comfort product family. It features a Type 1 vehicle connector on one end and open cable ends on the other, designed for electric vehicle charging applications. The cable has a length of 5 meters and is black in color with a straight configuration. It supports a permanent current of 40 A at 250 V AC, delivering up to 10 kW of power. The internal cable structure consists of 1x18AWG and 3x10AWG conductors.
Feature Summary
- Designed for single-phase AC charging of electric vehicles
- Features a Type 1 vehicle connector paired with open cable ends
- Constructed with durable black jacketing and straight geometry
Applications
- Charging electric vehicles via alternating current
- Integration into EV charging infrastructure
- Sector coupling and renewable energy applications
Procurement Notes
Verify that the specific application requires open cable ends rather than a mating connector. Confirm compatibility with local electrical standards for 250 V AC and 40 A continuous load. Ensure the Type 1 connector matches the vehicle inlet type. Check for any required certifications such as EAC or DNV if operating in regulated regions.
Selection Notes
Select this model when a fixed-length 5-meter connection between a Type 1 port and open wiring is needed. Consider the 10 kW power rating against the total load requirements. Evaluate the need for the CHARX connect comfort series features versus standard industrial cables. Ensure the open ends allow for proper termination within the target equipment.
Part Context
This component is part of Phoenix Contact's electrification portfolio, specifically the CHARX connect comfort series. It addresses the growing demand for efficient electric mobility solutions. The product supports sector coupling by facilitating reliable power transfer for EVs. It complements Phoenix Contact's broader automation and networking offerings.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify pinout and insulation ratings before considering alternative manufacturers.
FAQ
What is the maximum continuous current rating?
The cable supports a permanent current of 40 A.
What type of connector is used on the vehicle side?
It uses a Type 1 vehicle charging connector.
