1494976

Overview

Phoenix Contact part number 1494976 is a housing half-shell designed for the UCS series. It creates a housing with dimensions of 125 mm x 87 mm and includes provisions for a heatsink. The component is prepared to accommodate the specific heatsink model UCS HS-HH. It complies with IEC 60695-2-11:2014-02 standards, supporting operation at temperatures up to 850 °C under specified test conditions.

Feature Summary

• Designed specifically for creating UCS housings with defined dimensions
• Prepared to accommodate a dedicated heatsink unit
• Complies with international flammability safety standards

Applications

• Construction of industrial electrical enclosures
• Integration with UCS series heatsink systems
• Miniature case assembly for heavy duty power connectors

Procurement Notes

Verify the exact part number 1494976 against official Phoenix Contact documentation to ensure compatibility with the intended UCS housing dimensions and heatsink requirements. Confirm that the application environment aligns with the specified temperature ratings and material standards before procurement.

Selection Notes

Select this half-shell when constructing a UCS enclosure requiring dimensions of 125 mm by 87 mm. Ensure the design incorporates the compatible heatsink model UCS HS-HH. Verify that the thermal and mechanical requirements of the final assembly match the specifications provided in the manufacturer's datasheet.

Part Context

This component belongs to the Phoenix Contact UCS (Universal Compact System) series, which provides modular solutions for industrial automation. The half-shell serves as a structural element for custom-sized enclosures within this system, allowing for tailored protection and heat management configurations.

Replacement Considerations

No public confirmed substitute part numbers are available for this specific component.
