1494977

Overview

Phoenix Contact part number 1494977 is a housing half-shell component designed for the UCS enclosure system. It corresponds to the model designation UCS HH-HS 125-87 9005. This specific half-shell is engineered to create a custom enclosure with dimensions of 125 mm by 87 mm and includes an integrated heatsink structure. The unit is prepared to accommodate a corresponding heatsink assembly, facilitating thermal management within the assembled housing configuration.

Feature Summary

• Designed as a half-shell for constructing custom UCS enclosures
• Integrated heatsink structure for thermal management
• Prepared mounting interface for compatible heatsink assemblies

Applications

• Custom industrial control enclosure construction
• Thermal management integration in automation housings
• UCS system modular housing assembly

Procurement Notes

Verify that the required enclosure dimensions match the specified 125 mm x 87 mm format before ordering. Confirm compatibility with the intended UCS HS-HH heatsink assembly to ensure proper fitment. Check current availability status as lead times may vary. Ensure this half-shell is paired with the appropriate mating shell to complete the enclosure assembly.

Selection Notes

Select this component when a custom-sized UCS enclosure with built-in thermal dissipation capabilities is required. The 125x87 mm footprint defines the internal volume constraints. Verify that the application environment supports the material properties of the housing. Ensure the design accommodates the necessary mounting hardware for the heatsink component.

Part Context

This component belongs to the Phoenix Contact UCS (Universal Compact System) series, which provides modular solutions for industrial automation enclosures. The UCS system allows for flexible customization of housing sizes and configurations. Part 1494977 serves as a structural element within this ecosystem, specifically addressing size and thermal requirements for compact control applications.

Replacement Considerations

The equivalent part number UCS HH-HS 125-87 9005 can be used for identification purposes. No direct cross-manufacturer substitutes are documented for this specific proprietary housing geometry.
