1499535

Overview

The Phoenix Contact 1499535 is a Y-shaped distribution unit from the IPD series, designed for industrial power distribution. It features a 2+PE connection profile with position markings for L, N, and PE. The component supports a rated voltage of 500 V AC/DC and a nominal current of 20 A. It operates under overvoltage category III and utilizes P coding for secure mating. The housing is luminous grey, measuring 72 mm in width and 48 mm in height.

Feature Summary

• Y-shaped distributor configuration for efficient power branching
• Secure P coding prevents incorrect mating connections
• Clear position marking identifies L, N, and PE terminals
• Robust construction suitable for overvoltage category III environments

Applications

• Industrial control cabinet power distribution
• Machine building electrical systems
• Automation technology signal and power routing

Procurement Notes

Verify the complete part number including suffixes to ensure correct coding and pin assignment. Confirm that the required overvoltage category III rating aligns with your system design. Check physical dimensions against available mounting space in the enclosure. Ensure compatibility with existing circular connector interfaces before procurement.

Selection Notes

Select this model when a Y-branching topology is required for 20 A circuits. Verify that the P coding matches the mating connectors in the assembly. Consider the luminous grey color for visual identification within complex wiring schemes. Ensure the installation environment meets the specified insulation and overvoltage requirements.

Part Context

This component belongs to the Phoenix Contact IPD series of circular connector assemblies. It serves as a specialized distribution unit within the 1499 series family. The product integrates directly into industrial connectivity systems requiring reliable power splitting without soldering.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify exact dimensional and electrical compatibility if considering alternative distributors.
